Pixel Pitch | 1.89mm | 2.6mm | 2.97mm | 3.9mm |
|---|---|---|---|---|
Pixel Structure | 3INI SMD | 3INI SMD | 3INI SMD | 3INI SMD |
Pixel Density | 279947/㎡ | 147474/㎡ | 113367/㎡ | 65536/㎡ |
Module Resolution | 132*132dots | 96*96dots | 84*84dots | 64*64dots |
Module Size(WXH) | 250mm*250mm | 250mm*250mm | 250mm*250mm | 250mm*250mm |
White Balance Brightness | 800-1000cd/㎡ | 800-1000cd/㎡ | 800-1000cd/㎡ | 800-1000cd/㎡ |
Color Temperature | 2000K-12500K | 2000K-12500K | 2000K-12500K | 2000K-12500K |
Horizontal Viewing Angle | ≥160° | ≥160° | ≥160° | ≥160° |
Optimal Viewing Distance | ≥2m | ≥3m | ≥3m | ≥4m |
Contrast | ≥5000:1 | ≥5000:1 | ≥5000:1 | ≥5000:1 |
Grayscale | 12-14Bit | 12-14Bit | 12-14Bit | 12-14Bit |
Refresh Rate | ≥3840HZ | ≥3840HZ | ≥3840HZ | ≥3840HZ |
Continuous Working Time | 72H | 72H | 72H | 72H |
Life Span | 100,000H | 100,000H | 100,000H | 100,000H |
Protection Class | IP20 | IP20 | IP20 | IP20 |
Operating Voltage | DC 4.2V-5V | DC 4.2V-5V | DC 4.2V-5V | DC 4.2V-5V |
Max Power Consumption | 700W/㎡ | 700W/㎡ | 700W/㎡ | 700W/㎡ |
Average Power Consumption | 260W/㎡ | 260W/㎡ | 260W/㎡ | 260W/㎡ |
